Class "A" Amplifier

Objective  :  To Study the effect of different biasing network on output
gain and of and frequency response in  class A operation.
Specifications : instrument comprises of two fixed output DC Regulated
short circuit and overload protected Power Supply, One DC moving
coil Round meter, three different values of RL and RE selectable
using Bandswitch provided on front panel, circuit diagram is Printed
& components mounted on the front panel
Optional Accessories. :
Audio Frequency Function Generator
CRO
